Precise People Flow Monitoring, Empowering Intelligent Operation of Commercial and Public Spaces
I. Product Overview: The “Precision Monitoring Expert” in People Counting
FOORIR AI People Counting Terminal (Model: HX-CCD21) adopts 3D vision recognition + AI algorithm, which can accurately identify pedestrian contours and eliminate occlusion interference. As the core model of FOORIR’s people counting product line, HX-CCD21 integrates all core functions to meet the refined management needs of various scenarios.
Core Functions of HX-CCD21
- Bidirectional people flow counting
- Dwell time statistics
- Gender and age recognition
- REID deduplication (avoid repeated counting of the same person)
- Employee identification (distinguish employees from customers/visitors)
- Adult/child distinction
Core Functional Accuracy Metrics
- Gender recognition accuracy: 95%
- Age group recognition accuracy: 80%
- Employee identification accuracy: 80%
- REID cross scene deduplication accuracy: 80%
| Key Performance Highlight: Counting accuracy reaches over 99% (based on actual scene test data), far exceeding industry average standards. |
Installation & Power Supply of HX-CCD21:
- Installation: Wall-mounted or ceiling-mounted (flexible for different space layouts)
- Power Supply: 12VDC, 2A (stable power supply, easy to install and maintain)
Wide Application Scenarios of HX-CCD21:
Shopping malls, supermarkets, subway stations, scenic spots, office buildings, parking lots, and other commercial and public spaces.
II. Authoritative Certification: Dual Guarantee of Safety and Performance
HX-CCD21 has passed strict international and national certifications, ensuring safe and stable operation in various environments.
1. Electrical Safety Certification (GB 4943.1-2011, compliant with international safety standards)
- Marking & Description: Clearly marked with rated voltage, current, manufacturer and model; the marking will not fall off after friction.
- Electric Shock Protection: Class III equipment, adopting SELV safety voltage, no electric shock risk for operators and users.
- Mechanical Strength: Passed 250N pressure test and 500g steel ball drop test; the shell is intact, ensuring safe installation and use.
2. Protection Level Certification (IP66)
| IP66 is the core protection advantage of HX-CCD21, making it suitable for both indoor and outdoor harsh environments. |
- Dustproof: Fully dust-tight, suitable for underground shopping malls, scenic spots with high dust, and other dusty environments.
- Waterproof: Resists strong water jets from all directions (12.5L/min, 2.5-3m distance), and works stably in heavy rain and spray environments.
III. Full Environment Adaptation: From Extreme Cold to Extreme Heat
HX-CCD21 is designed with wide temperature adaptability, no additional protection or equipment replacement is required, reducing operation and maintenance costs.
1. Extreme Cold Resistance (-40℃ Tolerance)
- Test Condition: Constant temperature of -40℃ for 24 hours, HX-CCD21 works normally without freezing or crash.
- Application Scenarios: Outdoor areas in cold regions such as Northeast and Northwest China, including scenic observation decks, subway entrances and exits.
2. High-Low Temperature Cycle Adaptation (-10℃ to 55℃)
- Low Temperature: -10℃ for 24 hours, no freezing or crash.
- High Temperature: 55℃ for 24 hours, no overheating of the shell, stable operation of internal components.
- Application Scenarios: Outdoor areas with high temperature in summer in southern regions, such as parking lot entrances.
IV. High Reliability Design: Durable and Stable
HX-CCD21 adopts industrial-grade design, focusing on long-term stable operation to meet the 24-hour working needs of public and commercial spaces.
1. Vibration and Impact Resistance (IEC 61373:2010)
- Vibration Test: Vertical 1.01m/s² (10min), 5.75m/s² (5h), no abnormal operation.
- Impact Test: 30m/s² (horizontal/vertical), 50m/s² (longitudinal), the appearance of the equipment is intact, and the internal components are not damaged.
- Application Value: Can withstand the bumps during logistics and transportation, and the impact of large passenger flow in public places.
2. Long-Term Stable Operation (MTBF ≥ 50000h)
| Key Advantage of HX-CCD21: MTBF (Mean Time Between Failures) is ≥ 50000 hours, which means it can operate continuously for more than 5.7 years 24 hours a day. |
- Test Environment: Continuous operation for 86000 hours with zero failures.
- Application Value: Reduces downtime and maintenance costs, suitable for high-frequency operation scenarios.
- Application Scenarios: Subway stations, convenience stores, 24-hour supermarkets and other places that require long-term continuous operation.
V. Industry Application Value: Empowering Multiple Scenarios with HX-CCD21
1. Commercial Retail (Shopping Malls, Supermarkets)
- Real-time statistics of people flow and dwell time, helping optimize brand layout and promotion time periods.
- IP66 protection level is suitable for parking lot entrances; -40℃ low temperature adaptation meets the needs of northern winter.
2. Public Transportation (Subways, Bus Hubs)
- 24-hour stable operation, real-time monitoring of passenger flow density, assisting in crowd evacuation and management.
- Impact resistance design copes with crowded passenger flow during peak hours.
3. Cultural Tourism Scenic Spots (Scenic Areas, Amusement Parks)
- IP66 protection + -40℃ low temperature adaptation, suitable for outdoor entrances and observation decks.
- Combine people flow data with ticket data to optimize tour routes and crowd control strategies.
VI. Why Choose FOORIR HX-CCD21?
- Authoritative Certification: Passed GB 4943.1-2011 safety certification and IP66 protection test, complying with international standards.
- Full-Scenario Adaptation: -40℃ to 55℃ temperature range, suitable for north and south climates, both indoor and outdoor use.
- Long-Term Stability: MTBF ≥ 50000 hours, reducing operation and maintenance pressure and costs.
- Precise Data: 3D vision + AI algorithm, counting accuracy ≥ 99%, providing reliable data support for refined management.
- Flexible Installation: Wall-mounted and ceiling-mounted options, easy to install and adapt to different space sizes.
Whether it is commercial retail, public transportation or scenic area management, FOORIR HX-CCD21, with its high cost performance and high performance, will become a powerful assistant for your refined operation and management.
